Intel Core Ultra 5 235 (14 cores / up to 5,0GHz / 26MB / LGA1851 / VGA) Box cooler

Essentials Download Specifications Product Collection Intel® Core™ Ultra Processors (Series 2) Code Name Products formerly Arrow Lake Vertical Segment Desktop Processor Number 235 Overall Peak TOPS (Int8) 27 Recommended Customer Price $247.00-$257.00 CPU Specifications Total Cores 14 # of Performance-cores 6 # of Efficient-cores 8 Total Threads 14 Max Turbo Frequency 5 GHz Performance-core Max Turbo Frequency 5 GHz Efficient-core Max Turbo Frequency 4.4 GHz Performance-core Base Frequency 3.4 GHz Efficient-core Base Frequency 2.9 GHz Cache 24 MB Intel® Smart Cache Total L2 Cache 26 MB Processor Base Power 65 W Maximum Turbo Power 121 W Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes AI Software Frameworks Supported by CPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN CPU Lithography TSMC N3B Supplemental Information Marketing Status Launched Launch Date Q1'25 Embedded Options Available No Use Conditions PC/Client/Tablet, Workstation Datasheet View now Memory Specifications Max Memory Size (dependent on memory type) 192 GB Memory Types Up to DDR5 6400 MT/s Max # of Memory Channels 2 ECC Memory Supported ‡ Yes GPU Specifications GPU Name‡ Intel® Graphics Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 2 GHz GPU Peak TOPS (Int8) 6 Graphics Output DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b Xe-cores 3 Max Resolution (HDMI)‡ 4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL) Max Resolution (DP)‡ 8K @ 60Hz Max Resolution (eDP - Integrated Flat Panel)‡ 4K @ 60Hz DirectX* Support 12 OpenGL* Support 4.5 OpenCL* Support 3 Intel® Quick Sync Video Yes # of Displays Supported ‡ 4 Device ID 0x7D67 Intel® Deep Learning Boost (Intel® DL Boost) on GPU Yes NPU Specifications NPU Name‡ Intel® AI Boost NPU Peak TOPS (Int8) 13 Sparsity Support Yes Windows Studio Effects Support Yes AI Software Frameworks Supported by NPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN Expansion Options Direct Media Interface (DMI) Revision 4 Max # of DMI Lanes 8 Intel® Thunderbolt™ 4 Yes Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations ‡ Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 Max # of PCI Express Lanes 24 Package Specifications Sockets Supported FCLGA1851 Thermal Solution Specification PCG 2022C Max Operating Temperature 105 °C Advanced Technologies Intel® Volume Management Device (VMD) Yes Intel® Gaussian & Neural Accelerator 3.5 Intel® Thread Director Yes Intel® Speed Shift Technology Yes Intel® Turbo Boost Technology ‡ 2.0 Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Security & Reliability Intel vPro® Eligibility ‡ Intel vPro® Enterprise Intel® Threat Detection Technology (TDT) Yes Intel® Active Management Technology (AMT) ‡ Yes Intel® Standard Manageability (ISM) ‡ Yes Intel® Remote Platform Erase (RPE) ‡ Yes Intel® One-Click Recovery ‡ Yes Intel® Control-Flow Enforcement Technology Yes Intel® Total Memory Encryption - Multi Key Yes Intel® AES New Instructions Yes Secure Key Yes Intel® Trusted Execution Technology ‡ Yes Execute Disable Bit ‡ Yes Intel® OS Guard Yes Intel® Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel® Stable IT Platform Program (SIPP) Yes Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡ Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
