Zyxel LTE7490-M904,LTE B1/3/5/7/8/20/28/38/40/41,WCDMA B1/3/5/8, Standard,EU/UK Plug,FCS, support CA B1+B3/7

System specifications IP networking Supports IPv4/IPv6 dual stack (NDP IPv6) DHCP server Supports ICMP Virtual Private Network (VPN) passthrough Supports NAT/NAPT Supports NAT DMZ Supports port forwarding/triggering Supports ALG Routing Supports router mode Supports bridge (IP pass-through) mode Supports dynamic DNS for first APN Supports remote management under bridge mode IP firewall Firewall can be enabled or disabled via GUI DoS attack prevention Supports SPI Application-level firewall Filters LAN MAC addresses Filters URLs Management Supports local/remote device management and firmware upgrade via TR-069, HTTP/web GUI and FTP APN management Account management PIN/PUK management Network selection Operating frequency band selection CLI/SSH (local and remote SSH access) Supports UPnP IGD Supports SSH with key access certification management Supports bandwidth/quota management Supports mobile apps (iOS and Android) for easy installation and local management only Supports remote throughput testing by TR-143 WiFi Protected Setup (WPS) Hidden SSID Hardware specifications LTE interface Standard-compliant: 3GPP UE DL Category 18, UL Category 13 Supports LTE bands: B1/B3/B5/B7/B8/B20/B28/38/40/41 Supports DL transmission mode TM1/2/3/4/6/7/8/9 LTE antennas: 4 embedded directional antennas of up to 8 dBi/element (4x4 MIMO) Supports DL 5xCA**, 2x2 MIMO Supports DL 3xCA, 4x4 MIMO, B1/3/7** Supports DL modulations QPSK, 16-QAM, 64-QAM and 256-QAM Supports UL modulations QPSK, 16-QAM and 64-QAM Supports UL 2xCA** intra-band, B3/7/38/40/41 Peak data rates: DL: 1.2 Gbps within 100 MHz bandwidth UL: 150 Mbps within 40 MHz bandwidth UMTS Air interface Standard-compliant: WCDMA bands 1/3/5/8 Supported frequencies: HSPA+/UMTS: 2100/1800/900/850 MHz (bands 1/3/5/8) WCDMA: 2100/1800/900/850 MHz HSPA+ downlink data rates up to 42 Mbps HSUPA uplink data rates up to 5.76 Mbps WiFi Air interface*** Wireless standards: 802.11 b/g/n, 2.4 GHz, 300 Mbps Wireless omni antennas: WiFi 2.4 GHz: 2x2 internal antennas up to 3 dBi Hardware Interface One Gigabit RJ-45 PoE LAN port One LED indicator for: Power status Internet status LTE signal strength WiFi status LAN status One WiFi on/off button One 3FF micro SIM card socket One reset to default button Power specifications Standard 802.3af/at Power over Ethernet (PoE) Power consumption at PoE < 16 W
