Ubiquiti model WAVE-AP-MICRO

Wide-coverage 60 GHz PtMP access point powered by Wave Technology.

• Max. total throughput: 5 Gbps (2.5 Gbps duplex)
• 90° sector coverage
• 5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)
• (1) 2.5 GbE WAN port
• 31* client capacity:
  • — Wave Pro (6 km link range)
  • — Wave Long-Range (6 km link range)
  • — Wave Nano (4 km link range)
  • — Wave Pico (0.9 km link range)
• Integrated GPS & Bluetooth

Mechanical
Dimensions 284 x 156 x 76 mm (11.2 x 6.1 x 3")
Weight 1.3 kg (2.9 lb)
Enclosure material Aluminum alloy, UV stabilized polycarbonate
Mount material Stainless steel, UV stabilized polycarbonate
Pole mount diameter 35 to 60 mm (1.4 to 2.4") on pipe outer diameter
Wind loading 87 N at 200 km/h (20 lbf at 125 mph)
Weatherproofing IPX6


Hardware
Processor Quad-core ARM® Cortex®-A53 at 1.4 GHz
Memory DDR3L 512 MB
Networking interface (1) 1/2.5 GbE RJ45 port
Max. power consumption 24W
Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only
Power supply 48V DC, 0.65A, 2.5 GbE PoE adapter (Included)
Supported voltage range 44–54V DC
22–27V DC
GPS Yes
Button Factory reset
LEDs Power, Ethernet, GPS, Link
Ambient operating temperature -40 to 60° C (-40 to 140° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications FCC, IC, CE


Software
Operating mode PtMP access point
Ubiquiti specific features Wave AI, discovery protocol
Services UISP, ping watchdog, NTP client, SNMP
Tools Antenna alignment, discovery utility, ping, trace route, speed test, cable test*, site survey*
*FW version 3.3.0 and later.
Network Bridge mode
Application requirements UISP web: Version 2.2.11 and later
UISP mobile iOS™: Version 2.25.1 and later
UISP mobile Android™: Version 2.27.5 and later


System
Total throughput 5 Gbps (2.5 Gbps duplex)
Supported clients count 31*
*FW version 3.4.0 and later.
Max. range Connecting to a Wave Pro: up to 6 km
Connecting to a Wave Long-Range: up to 6 km
Connecting to a Wave Nano: up to 4 km
Connecting to a Wave Pico: up to 0.9 km
Encryption WPA2-PSK (AES)


RF
Operating frequency* 57–71 GHz
*Depends on regulatory region.
Channel bandwidth 2160, 1080, 540* MHz
*FW version 3.3.0 and later.
Operating channels* 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz
*Depends on regulatory region.
Modulation 16QAM, QPSK
Antenna gain 20 dBi
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 90°
Elevation: 3 dB 7°
Electrical downtilt 0°


Back-Up RF
WiFi standard 802.11ax (WiFi 6)
Operating frequency*
US/CA
Worldwide
U-NII-1 5150 - 5250 MHz
U-NII-2A 5250 - 5350 MHz
U-NII-2C 5470 - 5725 MHz
U-NII-3 5725 - 5850 MHz

5150 - 5875 MHz
*Depends on regulatory region.
Channel bandwidth 20, 40, 80 MHz
Modulation BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6)
Antenna gain 13.5 dBi
Polarization Dual-linear
Beamwidth Azimuth: 6 dB 90°
Elevation: 6 dB 25°
Cross-pol isolation 10 dB
Electric downtilt 0°


LEDs
Power Flashing white: bootup in progress
White: not connected to UISP application
Blue: connected to UISP application
Flashing blue: locate in progress
Blue/white: firmware upgrade in progress
Ethernet Flashing blue: Ethernet traffic detected
GPS Blue: receiving at least(4) GPS satellite signal
Link Blue: 60 GHz link
White: 5 GHz link
